An exterior wall junction consists of concrete masonry units coated with elastomeric coating on the interior face and clad with exterior aluminum panels. A fiberglass sub-girt supports the cladding assembly over four-inch insulation. Joints between panels and adjacent construction are sealed with a sealant and backer rod. A minimum six-inch air or insulation barrier component is detailed at the corner transition.
14 4" ALUM PANEL AB-01A OR AB-01B AB-02 MIN 6" AB-02 MIN 6" AB-02 SE-01 AND BACKER ROD 4" INS-01A FIBERGLASS SUB-GIRT ELC-01 ELASTOMERIC COATING CMU SE-01 AND BACKER ROD ALUM PANEL ALUM PANEL SE-01 AND BACKER ROD 2 A840 PROPERTY LINE 5/8" 4" 5/8" PROVIDE SE-01 AND BACKER ROD AT ALL EXTERIOR WALL PENETRATIONS 1"
