A five-eighths-inch laminated glass panel terminates at a partition wall finished per schedule, secured by a metal base channel butted tight to the wall partition. Continuous clear sealant is applied at the glass-to-channel joints, and continuous sealant matching the aluminum frame is applied at the channel-to-wall junction.
CONTINUOUS SEALANT TO MATCH ALUM FRAME PTN AS SCHEDULED CONTINUOUS CLEAR SEALANT METAL BASE CHANNEL, BUTT TIGHT TO WALL PTN 5/8" LAMINATED GLASS PANEL, SEE FINISH PLANS FOR TYPE AND ELEVATION GLASS PANEL SEE PLAN 1/4" 1/4" 1/4"
