A hollow metal frame connects to a gypsum board partition framed with metal studs. The hollow metal glazing stop secures the glass with minimum number 10 countersunk flat head machine screws spaced at a maximum of 12 inches on center. The partition meets the frame head assembly with specified clearance dimensions and framing as indicated in the metal stud framing diagrams.
2" UON 3/4" 5/8" 1 15/16" 1/2" 1/2" 1 15/16" PARTN TYPE AS INDICATED PROVIDE FRAMING AS INDICATED BY MET STUD FRAMING DIAGRAMS HM GLAZING STOP GLASS TYPE AS SCHEDULED LINE OF ASSEMBLY BEYOND DOOR HEIGH AS SCHEDULED HM FRAME ATTACH W/MIN #10 CTSK FHMS, (2) MIN. MAX 12" O.C.
