A masonry partition wall connects to an overhead concrete floor or roof slab with a gap filled with mineral wool insulation. Alternating four-inch by twelve-inch by three-sixteenths-inch bent steel plates secure each side of the wall at four feet on center using half-inch expansion bolts with two and one-quarter inches of embedment. Spray-applied firestop material is applied to each side with a minimum one-half-inch overlap at the partition and deck. A four-inch minimum to six-inch maximum clearance is maintained to facilitate grouting of the bond beam.
SPRAY APPLIED FIRESTOP MATERIAL EACH SIDE - MIN 1/2" OVERLAP AT PARTITION AND DECK 4" MIN TO 6" MAX TO FACILITATE GROUTING OF BOND BEAM MF 05 - 4" X 12" X 3/16" X 4" BENT STL PLATE ALTERNATING EA SIDE AT 4'-0" OC FILL GAP BETWEEN SLAB AND TOP OF WALL WITH MINERAL WOOL INSULATION 1/2" EXP BOLTS WITH 2 1/4" EMBED CONCRETE FLOOR OR ROOF _ 2"
