These shaft wall intersection details show standard framing conditions for fire-rated partitions using steel CH studs, J runners, and E studs. Gypsum board of five-eighths inch thickness is applied in two layers across the partitions as scheduled. Corner beads protect the outside corners of the gypsum board assemblies. Inside corners and wall junctions tie intersecting fire-rated partitions together using steel runners and studs configured per partition type requirements.
STEEL J RUNNER STEEEL CH STUD WALL JUNCTION INSIDE CORNER STEEL CH STUD STEEL J RUNNER OR E STUD FIRE RATED PARTITION AS SCHEDULED SEE PARTITION TYPES SHEET STEEL J RUNNER OR E STUD CORNER BEAD 2 LAYERS 5/8" GYP BOARD FIRE RATED PARTITION AS SCHEDULED SEE PARTITION TYPES SHEET FIRE RATED PARTITION AS SCHEDULED SEE PARTITION TYPES SHEET OUTSIDE CORNER
