The plan detail outlines the minimum clearance required for a push side hinge approach door maneuvering space, establishing a dimension of one foot ten inches minimum. A supplementary note specifies that forty-eight inches minimum is required if the door has both a latch and a closer.
1'-10" MIN. PUSH SIDE HINGE APPROACH * NOTE: 48" MIN. IF DOOR HAS BOTH LATCH AND CLOSER
