This clerestory sill assembly features a bent aluminum sill set atop a framed wall with Morin metal panel cladding, insulation, and scheduled interior finishes. A painted steel horizontal mullion supports the double-glazed insulated glazing unit above. An aluminum sunshade fin extrusion with concealed fastening and an optional sunshade bracket attach externally.
INTERIOR FINISH AS SCHEDULED HORIZONTAL MULLION, STEEL PTD IGU, DOUBLE GLAZED AS SCHEDULED MORIN METAL PANEL CLADDING SUNSHADE BRACKET AS NEEDED ALUMNIUM SILL, BENT ALUMINUM SUNSHADE FIN EXTRUSION, CONCEALED FASTENING
