Gravelbags are arranged at a forty-five-degree angle relative to the flow line, with spacing intervals defined per the gravelbag spacing table below. The layout incorporates one-half intervals and directional flow indicators along the flow line. Detail callout B on sheet CER201 references the specific gravelbag configuration requirements.
