Cylindrical pipe penetrations pass through rated wall or floor assemblies with zero direct contact between the penetrating material and the assembly. Annular spaces are maintained at a maximum of one-half inch for pipes greater than one inch in diameter, and between one-quarter and one-half inch for pipes less than one inch in diameter. Fire caulk is applied to each side of the penetration per Section 07 84 00. Required 'T' or 'F' ratings must be provided for penetrations in rated assemblies.
SEE ASSEMBLIES MAX 1/2" >1" DIA MAX 1/2" FOR PIPES >1" DIA. FOR PIPES <1" DIA. NOTE: 1. PROVIDE REQUIRED "T" OR "F" RATING FOR PENETRATIONS IN RATED ASSEMBLIES 2. PENETRATIONS SHOULD HAVE NO CONTACT BETWEEN THE MATERIAL PENETRATING THE ASSEMBLY AND THE ASSEMBY/BUILDING. FIRE CAULK EACH SIDE FIRE CAULK EACH SIDE CYLINDRICAL PENETRATION; SEE MECHANICAL, ELECTRICAL, AND PLUMBING DRAWINGS 07 84 00 - FIRESTOPPING 07 84 00 - FIRESTOPPING SEE ASSEMBLIES MAX 1/4" - 1/2" < 1" DIA MAX 1/4" - 1/2"
