One-quarter-inch tempered glass is set into an aluminum glazing channel bedded in clear sealant. The channel rests upon a one-half-inch solid surface panel designated as SS2, supported by a three-eighths-inch substrate. The assembly includes one-half-inch dimensional clearances and joint seals on each side.
ALUM. GLAZING CHANNEL, BED IN CLEAR SEALANT 1/4" TEMPERED GLASS 1/2" SOLID SURFACE, SS2 ON 3/8" SUBSTRATE 1/2" 1/2" EQ. 1/2" EQ. 1" 1/2" SEAL, EACH SIDE
