An intermediate grade beam cross-section features the concrete foundation member with four-leg crossties and internal reinforcing bars. The assembly maintains a four-inch concrete clearance as indicated on the drawing. A grid line aligns with a wall extending upward from the grade beam. A separate tie configuration diagram presents the four-leg crosstie layout.
NOTE: THIS EXAMPLE IS CROSSTIES WITH 4 LEGS CROSS-SECTION "B" INTERMEDIATE GRADE BEAM TIE CONFIGURATION GRID NOTE: FOR BALANCE OF INFORMATION, SEE CROSS SECTION "A" ABOVE CROSSTIE (LEGS) 4" CLR.
