A continuous steel J-runner secures the partition framing, which is filled with sound attenuation batt insulation. The hoistway entrance frame is anchored using Z-clips spaced six inches from the top and bottom, and at a maximum of twenty-four inches on center. The edge of the metal sill sits below the assembly alongside the hoistway entrance door.
EDGE OF METAL SILL BELOW Z-CLIPS 6" FROM TOP AND BOT. OF FRAME AND 24" O.C. MAX. 09 2116 CONTINUOUS STEEL J-RUNNER 2" 1/2" 14 2100 HOISTWAY ENTRANCE FRAME SOUND ATTENUATION BATT INSULATION 2-HOUR SHAFT PARTITION SEE PARTITION DETAILS CLEAR HOISTWAY 14 2100 HOISTWAY ENTRANCE DOOR PARTITION TYPES VARIES - SEE 2 1/2" DOOR PANEL WIDTH EDGE OF METAL SILL BELOW Z-CLIPS 6" FROM TOP AND BOT. OF FRAME AND 24" O.C. MAX. SEE PARTITION DETAILS CLEAR HOISTWAY
