Three-quarter-inch plywood corner and end fillers with plastic laminate finish match adjacent base and upper cabinets. The corner filler maintains a two-and-a-half-inch minimum width and may vary according to field conditions. End fillers are installed where required against the existing gypsum board wall.
3/4" PLYWOOD CORNER FILLERS W/ PLASTIC LAMINATE TO MATCH ADJACENT CABINETS BASE CABINET W/ DRAWER 2-1/2" MINIMUM PLAN VIEW *CORNER FILLER WIDTH MAY VARY, ACCORDING TO FIELD CONDITIONS (TYPICAL CORNER FILLER FOR BASE & UPPER CABINETS) 3/4" PLYWOOD END FILLERS W/ PLASTIC LAMINATE TO MATCH ADJACENT CABINETS WHERE REQ'D EXISTING GYP. BD. WALL
