An aluminum storefront head profile ties into the building exterior wall assembly directly beneath cold-formed metal framing. A sheet-applied weather-resistive barrier and exterior insulation back the wall, transitioning to a fastened aluminum flashing above the storefront profile. A sealant joint with backer rod seals the interface between the head member and the metal panel assembly. The glazing unit features laminated low-iron vision glass installed within the aluminum framing members.
INSULATING-GLASS UNIT: LAMINATED LOW-IRON VISION GLASS, GL02 ALUMINUM STOREFRONT WALL SYSTEM, EW-03 METAL PLATE PANEL, MP-01 @ PHASE 1 & MP-03 @ PHASE 2 ALUMINUM FLASHING, FASTENED INS-03 SHEET-APPLIED WEATHER RESISTIVE BARRIER, AB-01 SE-01 w/ BACKER ROD COLD-FORMED METAL FRAMING
