The assembly consists of a mitered frame front placard measuring twenty-six inches in height by three-quarters of an inch thick. An inner sleeve and an outer sleeve nest together behind the front placard with a depth of five inches. The inner sleeve measures thirteen and three-eighths inches high, while the outer sleeve extends to fifteen and seven-eighths inches high. Vertical dimensions detail the relative positioning and clearances of the sleeves and placard components.
MITERED FRAME FRONT PLACARD OUTER SLEEVE INNER SLEEVE 3/4" 5" 15 7/8" 13 3/8" 3/4" 11 5/8" 26"
