The assembly bears on a concrete structural slab with a concrete topping slab, supporting a wall framed per plan with a half-inch cementitious backer board and porcelain tile adhered via a tile bond coat. A continuous sheet metal angle anchors the transition, framed with aluminum tile trim pieces measuring three-eighths of an inch and one-quarter of an inch. The floor finish consists of a terrazzo floor and cove base installed over a moisture barrier with a crack suppression membrane and a one-eighth-inch divider strip.
CONCRETE STRUCTURAL SLAB CONCRETE TOPPING SLAB WALL PER PLAN 3/8" ALUMINUM TILE TRIM 1/2" CEMENTITIOUS BACKER BOARD PORCELAIN TILE PER FINISH SCHEDULE 3/ 8" 1 5/8" CONTINUOUS SHEET METAL ANGLE TILE BOND COAT TERRAZZO FLOOR & COVE BASE 1/2" CEMENTITIOUS BACKER BOARD 1 " MOISTURE BARRIER W/ CRACK SUPPRESSION MEMBRANE 1/4" ALUMINUM TILE TRIM PORCELAIN TILE 1/8" DIVIDER STRIP 3/8" 3/8" 4" 4" 1/8"
