Circuit connections run from a lighting control panel to multiple lighting fixtures including a 240-watt chandelier, two 96-watt wall sconces, a 348-watt perimeter downlight circuit, and a 174-watt emergency perimeter downlight circuit. A low-voltage switch at the entry door connects via a low-voltage switch symbol with number 15 designation to the lighting control system. Circuits are routed through twenty-ampere single-pole breakers and typical lighting relays, with circuit designations such as LCP2-18, LCP2-17, LCP2-16, and LCP2-39. Power distribution includes 120-volt standard feeds and 277-volt standard and emergency feeds.
