Suspended ceiling intersections at vertical wall construction are detailed for two conditions per the California Building Code. The first condition incorporates seismic bracing wires attached to framing members above the ceiling plane. The second condition utilizes perimeter wall angles supporting the ceiling membrane directly at the partition wall. Fasteners secure framing components to adjacent vertical surfaces.
(A) AT CEILINGS WITH SEISMIC BRACING, PER CBC (B) AT CEILINGS WITHOUT SEISMIC BRACING, PER CBC
