A hollow metal frame integrates with a metal stud partition wall supporting ceiling finishes and a door leaf. The hollow metal frame aligns below the partition framing with specified clearances, including a two-inch vertical dimension and a half-inch minimum ceiling finish clearance. A gasket is provided at the door stop to receive the door type as scheduled. Partition framing and finishes are installed per architectural schedules and framing diagrams.
1 1/8" FINISH AS SCHEDULED 2" MIN 1/2" CEILING FINISH AS SCHEDULED 1/2" PARTN TYPE AS INDICATED PROVIDE FRAMING AS INDICATED BY MET STUD FRAMING DIAGRAMS GASKET AS SCHEDULED DOOR TYPE AS SCHEDULED LINE OF ASSEMBLY BEYOND DOOR HEIGH AS SCHEDULED HM FRAME
