A pipe passes through a single-ply roofing membrane and a minimum R-30 rigid insulation layer over treated wood blocking as required. A two-pound cone-shaped lead flashing or a galvanized watertight umbrella extends twelve inches minimum above the roof level and wraps into the top of the pipe with a one-inch minimum inset. The flashing cone is fully adhered and sealed to the roofing membrane and wrapped with a membrane transition sheet. Stainless steel clamps secure the top of the umbrella and lead flashing over the pipe, set in a continuous bed of mastic.
MEMBRANE TRANSITION SHEET GALV WATER TIGHT UMBRELLA (SET IN SEALANT) S.S. CLAMP WRAP UMBRELLA OVER TOP OF PIPE 12" MIN. MEMBRANE TRANSITION SHEET S.S. CLAMP WRAP 2 LB. CONE SHAPED LEAD FLASHING INTO TOP OF PIPE, EXTEND MIN. 12" ABOVE ROOF LEVEL. SEAL IN CONT BED OF MASTIC 12" MIN. MIN. 2" LAP 1" MIN. SINGLE PLY ROOFING MEMBRANE RIGID INSULATION, R-30 MIN. FULLY ADHERE CONE TO ROOFING MEMBRANE TREATED WOOD BLOCKING AS REQ'D FULLY ADHERE & SEAL ROOFING CONE TO PIPE SINGLE PLY ROOFING MEMBRANE RIGID INSULATION, R-30 MIN. FULLY ADHERE CONE TO ROOFING MEMBRANE TREATED WOOD BLOCKING AS REQ'D FULLY ADHERE & SEAL ROOFING CONE TO PIPE D
