Fiber cement exterior cladding panels attach with a concealed fastener system to 16 gauge Z-furring over two inches of rigid insulation and a weather barrier. A quarter-inch joint clearance is maintained at the window frame return. The assembly is mirrored at similar conditions.
WEATHER BARRIER 16 ga Z-FURRING 2" RIGID INSULATION FIBER CEMENT PANEL CONCEALED FASTENER SYSTEM FIBER CEMENT EXTERIOR CLADDING 1/4" NOTE: MIRRORED AT SIM CONDITION
