A door assembly featuring a sweep and threshold meets an eight-inch threshold height condition adjacent to a floor panel. The floor buildup includes a quarter-inch leveling sand layer and a three-and-three-quarter-inch total thickness of tile, grout, and concrete by others. A four-inch dimension notes the panel thickness, resting over an existing floor with a mandatory two-inch backfill required by others.
SECTION F - F 8" 4" THRESHOLD SWEEP DOOR EXISTING FLOOR FLOOR PANEL 2" MANDATORY BACKFILL REQUIRED (BY OTHERS) TILE/GROUT/CONCRETE 3 3/4" TOTAL THICKNESS (BY OTHERS) 1/4" LEVELING SAND (BY OTHERS)
