Typical Glass Guardrail and Handrail Detail at Stair Landing

Materials

Steel Stainless Steel Glass / Glazing

Elements

Columns Stairs Railings / Guards Connections / Plates

Connections

HSS Connection Welded Connection

About this detail

A glass guardrail assembly is mounted to a painted hollow structural section stair stringer and channel. A three-inch diameter stainless steel top rail and one-and-a-half-inch diameter stainless steel handrail are supported by stainless steel brackets and a two-inch by two-inch painted steel post. The half-inch laminated, tempered glass infill panel is secured at the top and bottom into two-inch by two-inch painted steel post brackets and U-shape bent plate steel. Posts are spaced equally in each run with a five-foot maximum center-to-center spacing.
