These architectural details illustrate the hardware components for an aluminum tube gate assembly. The hinge detail utilizes a one-half-inch steel plate connected via a field-welded female zerk end to the post and a male end attached to the gate, with an optional stop welded above to prevent lift-off. The gate latch detail features two-by-four rectangular aluminum tubing secured with a one-half-by-one-and-a-half-inch aluminum flat bar bolt and a locking "L" handle. The drop rod detail incorporates a padlockable slide rod spanning two feet and one inch with one-inch and five-and-a-half-inch dimensional clearances.
5 1/2" 1" HINGE DETAIL GATE LATCH DETAIL 1/2" STEEL PLATE 2'-1" PADLOCKABLE SLIDE BOLT DROP ROD DETAIL LOCKING "L" HANDLE 1/2" X 1 1/2" ALUM FLAT BAR BOLT 2" X 4 RECT ALUM TUBE ZERK END IS FEMALE FIELD WELD TO POST MALE END ATTACHES TO GATE MALE DOWN FOR GATE LIFT OFF A "STOP" CAN BE WELDED TO THE GATE POST ABOVE THE HINGE TO PREVENT LIFT OFF
