The assembly consists of a gypsum board panel painted black, mounted in front of perimeter framing and fire-treated wood blocking. Millwork provides the supporting backing and decorative paneling, though this paneling is omitted at similar conditions. Technology devices and their mounting brackets are integrated per separate drawings. Wood framing members are coordinated to receive the applied finishes and hardware.
FIRE TREATED BLOCKING PERIMETER FRAMING AND BACKING PROVIDED BY MILLWORK SEE TECHNOLOGY FOR INFORMATION ON DEVICES AND MOUNTING BRACKET PAINT GYP BD BLACK DECORATIVE PANELING AND SUPPORT BLOCKING DOES NOT EXIST AT SIM CONDITION 3/4" 1' - 9 1/2" 1' - 11"
