This electrical diagram shows a straight splice vault designated as V-1212 measuring 8 feet by 20 feet by 9 feet 4 inches. The layout accommodates a straight splice Cindy 12kV circuit alongside provisions for one future circuit from the Platinum Substation and a Linda circuit from the Lewis Substation. The configuration includes one VGS-9 switch rated at 600 amperes, a 200 ampere circuit, another 200 ampere circuit, and a 600 ampere switch position. Additional dashed outlines designate allocated space for future VGS switches.
