A quarter-inch steel downspout cover is mounted just above the cleanout with four one-half-inch diameter drilled anchor bolts, utilizing two anchors on each side. The installation is positioned to avoid hindering the use of the cleanout on the concrete retaining wall.
1/4" STEEL D.S. COVER - MOUNT JUST ABOVE C.O. WITH (4) 1/2" DIAMETER DRILLED A.B. (2 EACH SIDE). INSTALLATION SHOULD NOT HINDER USE OF CLEANOUT. PLAN VIEW AT WALL PLAN VIEW AT DOCK DOCK RETAINING WALL
