A 3-5/8 inch by 18-gauge cold-formed steel stud extends minimum beyond the gypsum board finish. A 6-inch by 14-gauge track is fastened to each stud with four number-10 sheet metal screws, spanning a minimum of three studs. A 2-1/2 inch by 2-1/2 inch by 14-gauge by 5-inch long clip angle secures to the track with three number-10 sheet metal screws. A 2-1/2 inch by 18-gauge stud brace connects to the clip angle with two number-10 sheet metal screws at a maximum span of 9 feet and a maximum angle of 45 degrees.
1/2" 2" 1/2" 2" 1 1/2" MAX 45° 35/8"x18GA STUD MIN BEYOND GYP BOARD 6"x14GA TRACK W/ (4)-#10 SMS TO EACH STUD AS SHOWN IN SIMILAR (SPAN 3 STUDS MIN) 21/2"x21/2"x14GA x 5" LONG CLIP W/ (3)-#10 SMS TO TRACK 21/2"x18GA STUD BRACE W/ (2)-#10 SMS TO CLIP (9'-0" MAX SPAN) / 13 A673
