A bi-part sliding door configuration features a guide track measuring four and one-half inches by one and three-quarter inches. A pivot point is located at the lower section, with a breakout side and cover side designated. An optional factory prep switch location is detailed at seventy-four and one-half inches in height.
POINT PIVOT (114.3) GUIDE TRACK (44.5) 1-3/4" (6.4) 4-1/2" 1/4" BREAKOUT SIDE COVER SIDE Optional Factory Prep Switch Location @ 74-1/2"H
