A perimeter wall fixture is anchored to the concrete core wall and coordinates with a gypsum ceiling system. The lighting fixture assembly creates a cove detail adjacent to the core wall, maintaining a four-inch clearance from the vertical framing face and spaced six inches per architectural layout requirements.
