The hollow metal door and frame bear upon a threshold set over a concrete slab on grade with a maximum one-half inch clearance. An exterior concrete pad or sidewalk is provided by others adjacent to the assembly, bearing against a concrete panel below.
1/2" MAX. INTERIOR EXTERIOR HOLLOW METAL DOOR AND FRAME THRESHOLD, SEE SCHEDULE. SLAB ON GRADE CONCRETE PANEL CONCRETE PAD OR SIDEWALK, BY OTHERS DOOR BOTTOM, SEE SCHEDULE
