A riser clamp penetrates a structural floor deck with a three-eighths-inch full perimeter gap, sealed airtight using acoustic sealant and non-hardening fire safing where required. One layer of ribbed or waffled neoprene pad sits below the riser clamp, paired with a top friction pad and metal plate similar to a Mason WMSW pad. The annular space is packed with one inch of safing and batt insulation.
FULL PERIMETER 3/8" (± 1/8") SEALED AIRTIGHT USING ACOUSTIC SEALANT, NON- HARDENING FIRE SAFING IS EQUIVALENT , WHERE REQUIRED. REF. STRUCTURAL DWGS STRUCTURAL FLOOR DECK (1) LAYER RIBBED OR WAFFLED NEOPRENE PAD BELOW RISER CLAMP WITH TOP FRICTION PAD AND METAL PLATE SIMILAR TO MASON WMSW PAD 1" SAFING, BATT INSULATION SHEET TITLE
