A sheet metal duct is lined internally with one inch of black acoustical insulation and fitted with an integral volume damper. The duct passes through a ceiling assembly, with the neck size determined per the mechanical schedule and duct sizing per plans. The run extends and connects directly to the return or exhaust system.
1" BLACK ACOUSTICAL LINER VOLUME DAMPER CEILING 1. SHEET METAL DUCT. SEE PLANS FOR SIZE. 2. NECK SIZE PER SCHEDULE. 3. EXTEND AND CONNECT TO RETURN/EXHAUST SYSTEM. NOTES: 1 2 3
