The reinforcement layout for a concrete lintel section details the placement of continuous reinforcing bars and stirrups. The vertical concrete member includes typical panel reinforcement referenced to detail 1, with specific configurations of number 8, number 7, and number 5 bars on each face. Transverse reinforcement consists of number 3 bars spaced to match the vertical reinforcement. Clearances are provided with 1 and three-quarter inches and 1 and one-quarter inches on respective faces.
