A-E7TX4 — Tapered Rigid Insulation As Needed

Architectural · A-E7TX4

Tapered Rigid Insulation As Needed

Units: imperial
Sheet: A6.01
Discipline: Architectural

Materials

Membrane / Roofing Steel

Elements

Decks Insulation Roofs Waterproofing / Flashing

Text on the drawing

R2 ROOFING MEMBRANE COVER BOARD TAPERED RIGID INSULATION AS NEEDED 4" MINIMUM RIGID ROOF INSULATION STEEL ROOF DECK PER STRUCTURAL (ROOF DECK, TYP)

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
