This exterior wall assembly features a stone veneer facade separated by a one-inch air space from a two-inch layer of mineral wool insulation installed between vertical furring on clips. A fluid-applied weather barrier coats the exterior side of the half-inch exterior sheathing. The primary backup wall consists of six-inch metal studs sized per structural drawings, filled with batt insulation and backed by a vapor barrier. An interior finish as scheduled completes the room side of the assembly.
W6 Exterior Wall Assembly W6 1" AIR SPACE FLUID APPLIED WEATHER BARRIER 1/2" EXTERIOR SHEATHING INTERIOR FINISH AS SCHEDULED METAL STUD, SEE STRUCT BATT INSULATION STONE VENEER 6" VAPOR BARRIER 2" MINERAL WOOL INSULATION BETWEEN VERTICAL FURRING ON CLIPS GRID
