A recessed architectural reveal is formed directly into the exterior face of a concrete wall panel. The profile features three-quarter-inch dimensions establishing the depth and width of the aesthetic groove on the exterior side of the assembly.
EXTERIOR SIDE CONC. PANEL INTERIOR SIDE 0' - 0 3/4" 0' - 0 3/4" 0' - 0 3/4" 0' - 0 3/4"
