A four-stud wood jamb assembly tied together with edge and field screws. The members are secured using two number ten sheet metal screws spaced at twelve inches on center. Additional edge screws are spaced along the perimeter at one-eighth inch increments. Clearances of three-fourths of an inch are maintained at both ends of the assembly.
EDGE SCREW 1/8 1-12 EDGE SCREW FIELD SCREW PLAN VIEW 4-STUD JAMB 1/8 3 AT BOTH ENDS 3/4" (2) #10 SMS @ 12" OC 3/4"
