The assembly is constructed with one-inch gypsum shaftwall coreboard on one side supported by cold-formed metal stud framing. Acoustic batt insulation fills the stud cavity. Five-eighths-inch Type X gypsum wallboard is applied in multiple layers to the exterior face of the framing.
09 21 16 GYPSUM SHAFTWALL/COREBOARD, 1" - 09 21 16 METAL STUD FRAMING 09 21 16 ACOUSTIC BATT INSULATION 09 21 16 TYPE 'X' GYPSUM WALLBOARD, 5/8" 09 21 16 TYPE 'X' GYPSUM WALLBOARD, 5/8"
