An architectural concrete wall panel is detailed with an exterior reveal profile measuring three-quarters of an inch deep and three-quarters of an inch wide. The overall concrete panel thickness is seven and one-quarter inches. The exterior face incorporates the recessed groove detail for aesthetic articulation.
EXTERIOR SIDE CONC. PANEL 3/4" 3/4" 3/4" 3/4" 7 1/4"
