A corner joint assembly for a pre-finished aluminum railing and frame system. The assembly incorporates nine-sixteenths inch monolithic laminated glass panels designated as GL-6. Pre-finished aluminum components designated as E-MTL-02 form the structural frame and panel joint connections.
B 08 4400 PRE-FINISHED ALUMINUM, E-MTL-02 08 4400 9/16" [13 MM] MONOLITHIC, LAMINATED GLASS, GL-6 08 4400 PRE-FINISHED ALUMINUM, E-MTL-02 FRAME PANEL JOINT
