A single-ply membrane roofing system terminates at a parapet wall supported by a roof deck substrate. A membrane flashing extends up and over the parapet wall substrate, which is compatible with the roofing system. The membrane flashing seam is secured with a hot-air weld.
LINE OF ROOF DECK SINGLE-PLY MEMBRANE ROOFING SYSTEM HOT-AIR WELD MEMBRANE FLASHING LINE OF PARAPET / WALL SUBSTRATE COMPATIBLE WITH ROOFING SYSTEM
