A pendant loudspeaker is suspended from the building structure using a one-quarter-inch aircraft cable attached to a Hilti MW-EB eyebolt anchored into the low flute of the metal deck. A Simpson Titen HD coupler with a one-quarter-inch shank connects the suspension hardware. The speaker receives a loose cable from the AV contractor and EMT conduit routed from a standard one-gang junction box mounted to the ceiling assembly.
ADEQUATE SUPPORT STRUCTURE UNDER BOX, TYPICALLY CONSTRUCTED FROM UNISTRUT - THREADED ROD AND CONCRETE INSERTS. POUR CONCRETE PATCH / FLASHING COMPOUND OR CAULK AROUND THE PERIMETER OF THE TEMPORARY COVER. REMOVE TEMPORARY COVER AND ATTACH CONDUITS FIREPROOF UNDERSIDE OF BOX, GAP BETWEEN THE BOX AND FLOOR, AND CONDUITS VIEW B: LID OPTION 1 SECTION DETAIL VIEW E: LID OPTION 2 SECTION DETAIL VIEW C: LID OPTION 1 PLAN DETAIL VIEW F: LID OPTION 2 PLAN DETAIL LID FLUSH WITH FINISHED FLOOR FLOORBOX MFR: FSR INC. MODEL:FL-500P-6 CONDUIT (MAY ENTER FROM ALL 4 SIDES AND BOTTOM) FINISHED FLOOR (SEE ARCH DRAWINGS) PIANO HINGE COVER FLUSH WITH FINISHED FLOOR (ARCH TO DETERMINE LID FINISH DURING SUBMITTAL PHASE) FLOORBOX MFR: FSR INC. MODEL:FL-500P-6 1/4" CARPET FLANGE COVER WITH FINISHED FLOOR INTEGRATED INTO COVER (ARCH TO DETERMINE LID FINISH DURING SUBMITTAL PHASE) FLOORBOX MFR: FSR INC. MODEL:FL-500P-6 ADEQUATE SUPPORT STRUCTURE UNDER BOX, TYPICALLY CONSTRUCTED FROM UNISTRUT - THREADED ROD AND CONCRETE INSERTS. POUR CONCRETE PATCH / FLASHING COMPOUND OR CAULK AROUND THE PERIMETER OF THE TEMPORARY COVER. REMOVE TEMPORARY COVER AND ATTACH CONDUITS FLOORBOX MFR: FSR INC. MODEL:FL-500P-6 TOTAL CONDUIT KNOCKOUTS: 3/4": 8 1-1/2": 12 VOLTAGE DIVIDER 120VAC ENTERS THROUGH 1 OF 3 CONDUIT KNOCKOUTS IN AREA BEHIND VOLTAGE DIVIDER. (120VAC BY ELEC) A -- FLOORBOX TEMPORARY COVER (SEE LID DETAILS FOR OPTIONS) (ARCH TO DETERMINE LID FINISH DURING SUBMITTAL PHASE) (USE CONSTRUCTION COVER PROVIDED BY MFR UNTIL FINISHED FLOOR IS INSTALLED) ATTACH WITH EIGHT (8) MFR PROVIDED FLAT HEAD SCREWS & O-RINGS AFTER INSTALLING PANELS. CLEAN AREA IN AND AROUND ENTIRE TOP EDGE OF BOX AND APPLY 1/4" CONTINUOUS BEAD OF RTV SILICONE SEALANT. ATTACH WITH EIGHT (8) MFR PROVIDED FLAT HEAD SCREWS & O-RINGS AFTER INSTALLING PANELS. CLEAN AREA IN AND AROUND ENTIRE TOP EDGE OF BOX AND APPLY 1/4" CONTINUOUS BEAD OF RTV SILICONE SEALANT. NOTE: COVER SHIM KIT (FL-500P-CSK) MAY BE REQUIRED TO SET THE HEIGHT OF BOX "PRE-POUR" SO THE TOP OF FINISH COVER MATCHES TOP OF FINISHED FLOOR. NOTE: COVER SHIM KIT (FL-500P-CSK) MAY BE REQUIRED TO SET THE HEIGHT OF BOX "PRE-POUR" SO THE TOP OF FINISH COVER MATCHES TOP OF FINISHED FLOOR. BUILDING STRUCTURE (SEE ARCH DRAWINGS FOR EXACT CEILING ASSEMBLY) STANDARD 1-GANG JUNCTION BOX (BY ELEC) EMT CONDUIT (BY ELEC) LOOSE CABLE TO LOUDSPEAKER (BY AV CONTRACTOR) PENDENT 70V OR NETWORK LOUDSPEAKER SIMPSON TITEN HD COUPLER (1/4" SHANK, 1/4" COUPLER) 2 1/2" NOMINAL EMBEDMENT INTO LOW FLUTE PER ESR-2713 W/ 1/4" HILTI MW-EB EYEBOLT INTO BOTTOM FLUTE OF DECK 1/4" AIRCRAFT CABLE SUSPENSION WITH NICOPRESS SLEEVES 3" = 1'-0" 2 SHP PENDANT SPEAKER MOUNTING THIS ITEM WEIGHS LESS THAN 20 LBS.
