Accessibility clearances for water closets and in-swinging doors comply with California Building Code 11B-606. The layout specifies a minimum sixty-inch depth with fifty-six inches required at wall-mounted water closets and fifty-nine inches at floor-mounted water closets. Maneuvering spaces require a minimum sixty-inch or forty-eight-inch clearance depending on the configuration. A thirty-six-inch clearance is required when doors swing in, with doors permitted to swing over the hatched portion of the maneuvering space.
