Concrete tilt-up wall panels meet at an outside corner with a half-inch panel joint. A backer rod is installed at each face with continuous sealant running from the footing to the top of the panel and across the joint. A three-quarter-inch chamfer is provided at the exterior corner of the wall panels.
CONC. TILT- UP WALL PANEL BACKER ROD AT EACH FACE WITH CONTINUOUS SEALANT FROM FOOTING TO TOP OF PANEL AND ACROSS 1/2" PANEL JOINT TYPICAL 1/2" 3/4" CHAMFER TYPICAL
