Stepped bottom configuration of a concrete wall panel featuring typical vertical reinforcement and two number five bars measuring four feet long. A maximum three-inch step dimension is indicated at the corner transition. Bottom bars are referenced to detail one on sheet SD point three, and the stepped footing is referenced to detail fourteen.
