An intermediate stair landing features concrete fill placed over structural steel framing supported by steel channel stringers. Subframing at intermediate landings is detailed to remain flush with or above the bottom of the steel channel stringer. A cable railing system with adjustable fittings and stainless steel end caps by Feeney Architectural Products or approved equal is anchored at the landing. Post spacing is symmetrically dimensioned with equal increments across the landing zone.
REFER TO DETAIL 1/A6.06 FOR TYPICAL INFORMATION NOT SHOWN ADJUSTABLE FITTINGS WITH STAINLESS STEEL END CAPS AT INTERMEDIATE LANDINGS; BY FEENEY ARCHITECTURAL PRODUCTS OR APPROVED EQUAL CONCRETE FILL AT INTERMEDIATE LANDING OVER STRUCTURAL STEEL FRAMING EQ EQ 1'-5" 17 A6.06 SIM. SUBFRAMING AT INTERMEDIATE LANDINGS SHALL NOT EXTEND BELOW BOTTOM OF STEEL CHANNEL STRINGER, TYP.
