An aluminum door frame is set beneath a metal stud wall assembly framed with a continuous twenty-gauge metal runner and gypsum board facings. Batt insulation fills the wall cavity, and an additional gypsum board layer is added where required. A painted sheet metal closure trims the edge, and openings up to three feet wide align with the door frame.
6 3/8" 1 1/2" 6 3/8" BATT INSULATION ADDITIONAL GYP BD LAYER WHERE OCCURS GYP BOARD ALUM DOOR FRAME DOOR SEE DOOR SCHEDULE NOTE: FOR OPENINGS UP TO 3'-0" ALIGN W/ DOOR FRAME PAINTED SHEET METAL CLOSURE CONT. 20 GA. METAL RUNNER 1 1/2"
