A-DH3R9 — Plan - Stone Clad Column At Level 2, West

Architectural · A-DH3R9

Plan - Stone Clad Column At Level 2, West

Units: metric
Sheet: A-420
Discipline: Architectural

Materials

Elements

Columns Curtain Walls Facades / Cladding Walls Waterproofing / Flashing

Text on the drawing

NOTE: SEE DETAIL 1/-- FOR TYP NOTES NOT SHOWN HERE CURTAIN WALL SYSTEM, TYP SEALANT JOINT W/ BACKER ROD, TYP INTERIOR EXTERIOR FINISH BY TENANT, SHOWN DASHED B.S. B.S. B.S. B.S.
