An acoustic drywall edge trim is installed using an acoustic drywall trim profile with the tab trimmed off. One-inch drywall L-trim secures the edge condition. The junction is finished with mesh tape and joint compound, anchored with drywall screws.
AXTBC WITH TAB TRIMMED OFF FINISH WITH MESH TAPE AND JOINT COMPOUND DRYWALL SCREW 1" DRYWALL "L" TRIM 11 ACOUSTIC DRYWALL EDGE TRIM
